Furnaces of chemical industry and construction industry Pouring refractory bricks
| Quantity: | |
|---|---|
Product Description:
Product Brief Introduction:
1. AL2O3 : 36%-75%.
2. Can according to customers' requirements.
3. Used for Steel industry pouring.
Characteristics：
1) High-temperature endurable .
2) Good thermal shock and thermal spalling resistance.
3) Good resistance to abrasion and corrosion.
4) Won't pollute the molten steel.
Physical and chemical index:
ITEMS | Fireclay | High Alumina | Andalusite | |||
JZN-40 | JZN-36 | JZL-55 | JZL-65 | JZL-50 | JZH-57 | |
AL2O3 % (≥) | 40 | 36 | 55 | 65 | 50 | 57 |
Fe2O3 % (≤) | 2.0 | |||||
Refractoriness °C (≥) | 1720 | 1700 | 1770 | 1790 | 1770 | 1790 |
Permanent linear change | 1350°c x2h 0.1~-0.3 | 1350°c x2h 0.1~-0.3 | 1450°c x2h ±0.3 | 1500°c x2h ±0.3 | ||
Apparent porosity % | 17-15 | 17-25 | ≤24 | ≤24 | ≤26 | ≤26 |
Bulk density g/cm³ (≥) | 2.20 | 2.30 | 2.10 | 2.30 | ||
Application | Model casting | |||||
Quality Control:
We have perfect quality control system, Quality inspectors will conduct sampling inspection of all products, Substandard products will be prohibited leaving factory.
Our quality inspection items:
① Chemical analysis.
②Physical properties.
Packaging & shipping:
Packaging:
1. 25kg plastic woven bag or kraft paper bag in 1000-1500kg big bag.
2. 25kg plastic woven bag or kraft paper bag on pallet and covering by plastic films.
Shipping:
20 Foot Container can be loaded 24Tons,
40 Foot Container can be loaded 28Tons.
Company Description:
ZIBO ZHUOYUE REFRACTORY CO.,LTD is a specialized manufacturer and exporter of refractories in China. With more than 30 years production experience.
1. Mainly products: Refractory bricks, Refractory castables, Insulating bricks, Insulating castables, Calcined kaolin, Chamotte, Mullite, Ceramic fiber products, etc.
2. Production capacity : Equipped with 2 tunnel kilns , 4 shaft kilns,25 presses machine, 2 castables automatic batching production line,4 Particle and powder production lines,Production capacity of over 100,000 tons per year.
3. Main market : Products are exported to more than 30 countries (Such as South Korea, Japan, German, France, Italy, Indonesia, US, Australia, Malaysia, Philippines, Israel, Jordan, Turkey, Syria, Honduras, South Africa, China Taiwan and so on).
Our Services:
In order to make you more assured of our products, we can provide you with more services:
1. We can provide you with photos of every link of the product.
2. We can provide you with the authoritative test report of the product.
3. We will provide you with a comprehensive after-sales service, such as the quality of the product, construction programs,usage method,etc.
4. If the goods have quality problems, we will negotiate with you and pay compensation according to the evidence.
Product Description:
Product Brief Introduction:
1. AL2O3 : 36%-75%.
2. Can according to customers' requirements.
3. Used for Steel industry pouring.
Characteristics：
1) High-temperature endurable .
2) Good thermal shock and thermal spalling resistance.
3) Good resistance to abrasion and corrosion.
4) Won't pollute the molten steel.
Physical and chemical index:
ITEMS | Fireclay | High Alumina | Andalusite | |||
JZN-40 | JZN-36 | JZL-55 | JZL-65 | JZL-50 | JZH-57 | |
AL2O3 % (≥) | 40 | 36 | 55 | 65 | 50 | 57 |
Fe2O3 % (≤) | 2.0 | |||||
Refractoriness °C (≥) | 1720 | 1700 | 1770 | 1790 | 1770 | 1790 |
Permanent linear change | 1350°c x2h 0.1~-0.3 | 1350°c x2h 0.1~-0.3 | 1450°c x2h ±0.3 | 1500°c x2h ±0.3 | ||
Apparent porosity % | 17-15 | 17-25 | ≤24 | ≤24 | ≤26 | ≤26 |
Bulk density g/cm³ (≥) | 2.20 | 2.30 | 2.10 | 2.30 | ||
Application | Model casting | |||||
Quality Control:
We have perfect quality control system, Quality inspectors will conduct sampling inspection of all products, Substandard products will be prohibited leaving factory.
Our quality inspection items:
① Chemical analysis.
②Physical properties.
Packaging & shipping:
Packaging:
1. 25kg plastic woven bag or kraft paper bag in 1000-1500kg big bag.
2. 25kg plastic woven bag or kraft paper bag on pallet and covering by plastic films.
Shipping:
20 Foot Container can be loaded 24Tons,
40 Foot Container can be loaded 28Tons.
Company Description:
ZIBO ZHUOYUE REFRACTORY CO.,LTD is a specialized manufacturer and exporter of refractories in China. With more than 30 years production experience.
1. Mainly products: Refractory bricks, Refractory castables, Insulating bricks, Insulating castables, Calcined kaolin, Chamotte, Mullite, Ceramic fiber products, etc.
2. Production capacity : Equipped with 2 tunnel kilns , 4 shaft kilns,25 presses machine, 2 castables automatic batching production line,4 Particle and powder production lines,Production capacity of over 100,000 tons per year.
3. Main market : Products are exported to more than 30 countries (Such as South Korea, Japan, German, France, Italy, Indonesia, US, Australia, Malaysia, Philippines, Israel, Jordan, Turkey, Syria, Honduras, South Africa, China Taiwan and so on).
Our Services:
In order to make you more assured of our products, we can provide you with more services:
1. We can provide you with photos of every link of the product.
2. We can provide you with the authoritative test report of the product.
3. We will provide you with a comprehensive after-sales service, such as the quality of the product, construction programs,usage method,etc.
4. If the goods have quality problems, we will negotiate with you and pay compensation according to the evidence.
